E2000S is an intelligent aerial photogrammetric UAV system launched by Feima Robotics for professional users to meet the needs of high-efficiency, high-efficiency and high-precision aerial phtogrammetry and remote sensing applications. It is equipped with a 24.3 million-pixel aerial photographing module which can support two operating modes, i.e., orthographic and oblique. The standard take-off weight of the E2000S is 2.8 kg, the standard load is 200 g, and the endurance time is 60 minutes.E2000S is equipped with a high-precision differential GNSS board and dual-differential antennas, and can optionally be equipped with a physical GNSS base station to realize large-scale image-free control applications based on RTK and PPK fusion calculations. The E2000S comes standard with the software named UAVManager Professional Edition, which has various route modes for different application requirements and supports accurate three-dimensional route planning, precise terrain following flight, three-dimensional realtime flight monitoring. Also, the software supports GNSS fusion calculation, control point measurement, aerotriangulation, one-key to output and browse multiple data results such as TDOM, DOM, DEM, DSM and so on.
![](http://www.slam100.com/wp-content/uploads/2023/05/e2000s_bg-1001x1024.png)
![](http://www.slam100.com/wp-content/uploads/2023/05/E2000s_basic.png)
![](http://www.slam100.com/wp-content/uploads/2023/05/platform.png)
Image control-free topographic mapping
E2000S is equipped with 20 Hz high-precision differential GNSS board; At the same time, it is equipped with 24.3 M pixel APS-C frame sensor; supports orthophoto and oblique operation modes, has GCP-free mapping capabilities, and can adapt to various aerial survey applications.
Long endurance, high efficiency and high reliability
The hovering time at sea level for a single flight is 60 minutes. The modules such as IMU, barometer, magnetometer, and GNSS module adopt redundant design. The componets such as ultrasonic wave, optical flow module and double differential antennas are utilized to provide multiple guarantees. A number of components and the whole UAV platform have passed the reliability test to ensure product safety and reliability.
Dual-differential antenna
Double dual-differential antennas are the standard configurations of the E2000S, which enhance the antiinterference ability and help to operate in complex environments such as mining areas, bridges, and ship- borne take-off and landing platforms.
Precise terrain following flight
Combined with the software of UAVManager Professional Edition, the E2000S can achieve accurate terrain following flight, improving the image acquisition resolution and ensuring the consistency of image resolution.
![](http://www.slam100.com/wp-content/uploads/2023/05/bg-2.png)
![](http://www.slam100.com/wp-content/uploads/2023/05/e2000smod.png)
![](http://www.slam100.com/wp-content/uploads/2023/05/applicaton-case-1.png)
![](http://www.slam100.com/wp-content/uploads/2023/05/applicaton-case-1-1-1.png)
![](http://www.slam100.com/wp-content/uploads/2023/05/application-case-2.png)
![](http://www.slam100.com/wp-content/uploads/2023/05/application-case-2-2.png)
